NEO6-RNS
Exclusive model for Instant Dry Bag Noodle with high speed With thicker wrapping film.
Features
- Exclusive model for Instant Dry Bag Noodle with high speed With thicker wrapping film.
- With new Longsealer design, it is able to run empty bag and without product shape influence.
Also, no more film set up by hand which increase operation safety.
- More operational and safe by extra Endsealer stop switch.
| Target Item | Bag Noodles, etc. |
| Packaging Speed | Max. 300 pack/min (depend on kind of items and wrapping material) |
| Cut Pitch | 80～380mm |
| Main Motor | 200V 750W (AC Servo) 3 Units, Longsealer 200V 200W (AC Servo) |
| Power Consumption | Three Phase, 200V 4.5kW |
| Film Width | 450mm |
Read More
NEO6-620VBMUD
This pillow wrapper realizes unique Hermetic Pillow Package with pretty gusset and clean folding line that is processing on the straight single rolled high barrier soft touch nylon film without damage to its barrier performance.
Features
- This pollow wrapper realizes unique Hermetic Pillow Package with pretty gusset and clean folding line that is processing on the straight single rolled high barrier soft touch nylon film without damage to its barrier performance.
- It is able to do complete sealing with gusset without any damage to film layer. It means this machine can use soft film to package like pre-made bag.
- With special film transfer design, it is able to make beautiful gusset without product shape influence. It means this machine can make beautiful gusset with round shape product inside, such as German tree cake.
- Even product without tray canbe automatically feeded and packaged by belt devider or pusher-less auto-feeders. It is related to reduce running cost and scrap volume.
| Target Item | German tree cake, other snacks |
| Packaging Speed | Max. 40 pack/min (depend on kind of items and wrapping material) 4-side sealing: 35~100mm |
| Packing Speed | 30 ~ 120 packs/min (depends specification of product and pouch) |
| Main Motor | AC Servo 750W / AC Servo 400W (2 Units) / AC Servo 100W |
| Power Consumption | Three Phase 200V 8.5kw |
| Film Width | 590㎜ |
Read More
NEO6-615VBMUD
This wrapping machine receives dry noodles which are supplied from upper weight checker by timing hopper, and to reduce noodle scattering by Noodle End Organizer. Then it automatically to wrap items with designated film. Also, both loosen dry noodle and bundled dry noodle can be used at single machine.
Features
- This wrapping machine receives dry noodles which are supplied from upper weight checker by timing hopper, and to reduce noodle scattering by Noodle End Organizer. Then it automatically to wrap items with designated film. Also, both loosen dry noodle and bundled dry noodle can be used at single machine.
- Infeed conveyor width is easy to adjust by a handle depend on amount of dry noodle.
- Its safety and operation are improved during setup with individual stop switch to stop Endsealer as a pre-installed option.
| Target Item | Streight noodles100g～3000g |
| Packaging Speed | Max. 90 pack/min (in case with 2 units timing hopper) |
| Packing Speed | 30 ~ 120 packs/min (depends specification of product and pouch) |
| Cut Pitch | 80～500mm |
| Power Consumption | Three Phase 200V 6.0kw |
Read More
NEO6-415
Servo control technology. For exclusive product with fixed endsealer cut position.
Features
- Standard machine NEO series. Excellent machine specifications and operation. Easy operational without reading manual.
- This machine gives easy operation with large sized 12.1" color touch screen controller that also guides operation procedure.
- Independent Endsealer motion control gives easy and safety set up and also easy machine operation.
| Target Item | Pudding、Yogurt etc. |
| Packaging Speed | Max. 300 pack/min (depend on kind of items and wrapping material) |
| Cut Pitch | 90～470mm |
| Main Motor | 200V 750W (AC Servo) 3 Units |
| Power Consumption | Three Phase 200V 4.5kw |
| Film Width | 450mm |
Read More
NS350
This is succession machine of N-450A. As an exclusive machine of instant noodles, NS350 has improved function and easier to use.
Features
- Specialized model for instant dry noodles.
- More simple & compact, but remain heavy duties of N450A.
- More accurate registration control system is realized with fine control of servo motor at film driven part.
- Succeeding model of N-450A highly appreciated among users all over the world.
| Target Item | Noodles (Bag Noodles) |
| Packaging Speed | Max. 160 pack/min (depend on kind of items and wrapping material) |
| Standard Spec | Touch Panel Operation / Heater SSR Control Type |
| Maximum Film Width | 350mm |
| Power Consumption | Three Phase 200V 3.5kw |
Read More
